Product Summary

The TYN408G is a silicon controlled rectifier. It is designed for power supply up to 400Hz on resistive or inductive load.

Parametrics

TYN408G absolute maximum ratings: (1)IT(RMS), RMS on-state current: 25A; (2)IT(AV), average on-state current: 16A; (3)ITSM, non repetitive surge peak on-state current: 260A; (4)I2t, I2t value: 310A2s; (5)Tstg, storage temerpature range: -40 to 150℃; (6)Tj, storage and operating junction temperature range: -40 to 125℃.

Features

TYN408G features: (1)high surge capability; (2)high on-state current; (3)high stability and reliability.

Diagrams

TYN408G block diagram
