Product Summary

The STC12C5410AD is a single-chip microcontroller based on a high performance 1T architecture 8051 CPU, which is produced by STC MCU Limited. With the enhanced kernel, TC12C5410AD executes instructions in 1~6 clock cycles (about 8~12 times the rate of a standard 8051 device), and has a fully compatible instruction set with industrial-standard 8051 series microcontroller. In-System-Programming (ISP) and In-Application-Programming (IAP) support the users to upgrade the program and data in system.

Parametrics

STC12C5410AD absolute maximum ratings: (1)Srotage temperature TST -55 +125 ℃; (2)Operating temperature (I) TA -40 +85 ℃; (3)Operating temperature (C) TA 0 +70 ℃; (4)DC power supply (5V) VDD - VSS -0.3 +6.0 V; (5)DC power supply (3V) VDD - VSS -0.3 +4.0 V; (6)Voltage on any pin - -0.5 5.5 V.
