Product Summary

The PS2801-1-F3-A is an optically coupled isolator. It contains a GaAs light emitting diode and an NPN silicon phototransistor in a plastic SSOP for high density applications. This package has shield effect to cut off ambient light. The applications of PS2801-1-F3-A include Programmable logic controllers, Measuring instruments, Power supply and Hybrid IC.

Parametrics

PS2801-1-F3-A absolute maximum ratings: (1)Diode, Forward Current (DC), IF:50mA; Reverse Voltage, VR: 6V; Power Dissipation Derating, ΔPD/℃: 0.6mW/℃; Power Dissipation, PD: 60mW/ch; Peak Forward Current, IFP: 1A; (2)Transistor, Collector to Emitter Voltage, VCEO: 80V; Emitter to Collector Voltage, VECO: 6V; Collector Current, IC: 50mA/ch; Power Dissipation Derating, ΔPC/℃: 1.2 mW/℃; Power Dissipation, PC: 120mW/ch; (3)Isolation Voltage, BV: 2 500Vr.m.s; (4)Operating Ambient Temperature, TA: -55 to +100℃; (5)Storage Temperature, Tstg: -55 to +150℃.

Features

PS2801-1-F3-A features: (1)High isolation voltage (BV = 2 500 Vr.m.s.); (2)Small and thin package (4,16-pin SSOP, Pin pitch 1.27 mm); (3)High collector to emitter voltage (VCEO = 80 V); (4)High-speed switching (tr = 3μs TYP., tf = 5μs TYP.); (5)Ordering number of tape product: PS2801-1-F3, F4, PS2801-4-F3, F4; (6)Pb-Free product; (7)Safety standards: PS2801-1, -4; UL approved: File No. E72422; BSI approved: No. 8188, 8189; DIN EN60747-5-2 (VDE0884 Part2) approved (Option).

Diagrams

PS2801-1-F3-1 block diagram
