FMS6363

Low Cost Video Filter, SOP-8, -0.3 to 6 V, 50 mA, 30MHz

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.60~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.60~0.80

PartNumber:: FMS6363

Brand:: Fairchild Semiconductor - Fairchild | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Crystal's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-18

From Other Seller

Part Number:FMS6363
US $0.60 - 0.80
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
SIL9030CTU

US $2.50 - 5.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The FMS6363 is a Low Cost Video Filter (LCVF). It is intended to replace passive LC filters and drivers with a low-cost integrated device. Three 6th order filters provide improved image quality compared to typical lower order passive solutions. The applications of the FMS6363 are (1)Cable and Satellite set top boxes; (2)DVD players; (3)HDTV; (4)Personal Video Recorders (PVR); (5)Video On Demand (VOD).

Parametrics

FMS6363 absolute maximum ratings: (1)DC Supply Voltage: -0.3 to 6 V; (2)Analog and Digital I/O: -0.3 to Vcc + 0.3 V; (3)Output Current, Any One Channel (Do Not Exceed): 50 mA.

Features

FMS6363 features: (1)Three sixth-order 30MHz (HD) filters; (2)Transparent input clamping; (3)Single video load drive (2Vpp, 150Ω, AV = 6dB); (4)AC or DC-coupled inputs; (5)AC or DC-coupled outputs; (6)DC-coupled outputs eliminate AC-coupling capacitors; (7)5V only; (8)Lead (Pb) Free package- SOIC-8.
