Product Summary
The ULN2003AFWG is a high-voltage, high-current darlington driver. It is comprised of seven NPN darlington pairs. All units feature integral clamp diodes for switching inductive loads. The applications of the ULN2003AFWG are relay, hammer, lamp and display(LED) drivers.
Parametrics
ULN2003AFWG absolute maximum ratings: (1)output sustaining voltage: -0.5V to 50V; (2)output current:500mA/ch; (3)input voltage:-0.5V to 30V; (4)clamp diode reverse voltage:50V; (5)clamp diode forward current:500mA; (6)power dissipation: 0.54W; (7)operating temperature:-40℃ to 85℃; (8)storage temperature:-55℃ to 150℃.
Features
ULN2003AFWG features: (1)output current(single output) 500mA MAX; (2)high sustaining voltage output 50V min.; (3)output clamp diodes; (4)inputs compatible with various types of logic; (5)package type-AFW: SOL-16pin.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ULN2003AFWG |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
ULN2003AFWG(5,EL,M |
Toshiba |
Transistors Darlington 7CH. 50V/.5A IFD IC |
Data Sheet |
Negotiable |
|
||||||||||||
 |
ULN2003AFWG(O,M) |
Toshiba |
Transistors Darlington 7-ch 500mA 50V 2.7 kOhm 5V CMOS |
Data Sheet |
|
|
||||||||||||
|
ULN2003AFWG(O,NEHZ |
Toshiba |
Transistors Darlington 7-Ch 500mA 50V NPN Darlington Trans |
Data Sheet |
|
|
||||||||||||
|
ULN2003AFWG(O,EL,M |
Toshiba |
Transistors Darlington 7-ch 500mA 50V 2.7 kOhm 5V CMOS |
Data Sheet |
Negotiable |
|
||||||||||||
|
ULN2003AFWG(5,M) |
Toshiba |
Transistors Darlington 7CH. 50V/.5A IFD IC |
Data Sheet |
Negotiable |
|
||||||||||||
|
ULN2003AFWG(ONEHZA |
Toshiba |
Transistors Darlington INTERFACE DRIVER PB-FREE W / TTL |
Data Sheet |
Negotiable |
|
||||||||||||
|
ULN2003AFWG(SC,M) |
Toshiba |
Transistors Darlington 7CH. 50V/.5A IFD IC |
Data Sheet |
Negotiable |
|
||||||||||||
