SN74LVT16245BGQLR

SN74LVT16245BGQLR, Texas Instruments, BGA, bus transceiver, –0.5V to 4.6V, 64mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.20

PartNumber:: SN74LVT16245BGQLR

Brand:: Texas Instruments - TI | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Crystal's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-19

From Other Seller

Part Number:SN74LVT16245BGQLR
US $1.00 - 1.20
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
IRF3205

US $0.80 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN74LVT16245BGQLR is a 16-bit (dual-octal) noninverting 3-state transceivers designed for low-voltage(3.3-V) VCC operation, but with the capability to provide a TTL interface to a 5-V system environment.These devices are designed for asynchronous communication between two data buses. The logic levels of thedirection-control (DIR) input and the output-enable (OE) input activate either the B-port outputs or the A-portoutputs or place both output ports into the high-impedance mode. The device transmits data from the A bus tothe B bus when the B-port outputs are activated, and from the B bus to the A bus when the A-port outputs areactivated. The input circuitry on both A and B ports is always active and must have a logic HIGH or LOW levelapplied to prevent excess ICC and ICCZ.

Parametrics

SN74LVT16245BGQLR absolute maximum ratings: (1)Supply voltage range, VCC: –0.5V to 4.6V; (2)Input voltage range, VI:–0.5V to 7V; (3)Voltage range applied to any output in the high state or power-off state, VO:–0.5V to 7V; (4)Current into any output in the low state, IO: 128mA; (5)Current into any output in the high state, IO: 64mA; (6)Input clamp current, IIK (VI＜0): –50mA; (7)Output clamp current, IOK (VO＜0): –50mA; (8)Maximum power dissipation at TA = 55℃ (in still air): 0.85 W; (9)Storage temperature range, Tstg: –65℃ to 150℃.

Features

SN74LVT16245BGQLR featutes: (1)Member of the Texas Instruments Widebus Family; (2)State-of-the-Art Advanced BiCMOS: Technology (ABT) Design for 3.3-V Operation and Low Static-Power Dissipation; (3)Support Mixed-Mode Signal Operation: (5-V Input and Output Voltages With3.3-V VCC); (4)Support Unregulated Battery Operation Down to 2.7 V; (5)Typical V: OLP (Output Ground Bounce) <0.8 Vat VCC = 3.3 V, TA = 25℃.
