MAX3490EESA

transceiver, SOP8, +7V, MAX3490EESA, 667mW, axim

Rated 5 Rating 5 | reviews | Write a review

Price:: US $17.50~18.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $17.50~18.00

PartNumber:: MAX3490EESA

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Crystal's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-22

From Other Seller

Part Number:MAX3490EESA
US $17.50 - 18.00
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX3490EESA is a ±15kV ESD-protected, +3.3V, low-power transceiver for RS-485 and RS-422 communications. It contains one driver and one receiver. The applications of the MAX3490EESA include Telecommunications, Industrial-Control Local Area Networks, Transceivers for EMI-Sensitive Applications, Integrated Services Digital Networks, Packet Switching.

Parametrics

MAX3490EESA absolute maximum ratings: (1)Supply Voltage (VCC): +7V; (2)Control Input Voltage (RE, DE): -0.3V to +7V; (3)Driver Input Voltage (DI): -0.3V to +7V; (4)Driver Output Voltage (A, B, Y, Z): -7.5V to +12.5V; (5)Receiver Input Voltage (A, B): -7.5V to +12.5V; (6)Receiver Output Voltage (RO): -0.3V to (VCC + 0.3V); (7)Continuous Power Dissipation (TA = +70℃); (8)8-Pin SO (derate 5.88mW/℃ above +70℃): 471mW; (9)8-Pin Plastic DIP (derate 9.09mW/℃ above +70℃): 727mW; (10)14-Pin SO (derate 8.33mW/℃ above +70℃): 667mW; (11)14-Pin Plastic DIP (derate 10mW/℃ above +70℃): 800mW; (12)Operating Temperature Ranges: -40℃ to +85℃; (13)Storage Temperature Range: -65℃ to +150℃; (14)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX3490EESA features: (1)ESD Protection for RS-485 I/O Pins: ±15kV-Human Body Model, ±8kV-IEC 1000-4-2, Contact Discharge, ±15kV-IEC 1000-4-2, Air-Gap Discharge; (2)Operate from a Single +3.3V Supply-No Charge Pump Required; (3)Interoperable with +5V Logic; (4)Guaranteed 12Mbps Data Rate (MAX3485E/MAX3490E/MAX3491E); (5)Slew-Rate Limited for Errorless Data Transmission (MAX3483E/MAX3488E); (6)2nA Low-Current Shutdown Mode (MAX3483E/MAX3485E/MAX3486E/MAX3491E); (7)-7V to +12V Common-Mode Input Voltage Range; (8)Full-Duplex and Half-Duplex Versions Available.
