Product Summary

The MicrochipTechnology Inc. MCP3004-IP is a successive approximation 10-bit Analog-to-Digital (A/D) converter with on-board sample andhold circuitry. The MCP3004-IP is programmable to pro-vide two pseudo-differential input pairs or four single-ended inputs. Differential Nonlinearity (DNL) and Integral Nonlinearity (INL) are specified at ±1 LSB. Communication with the devices is accomplished using asimple serial interface compatible with the SPI protocol.

Parametrics

MCP3004-IP absolute maximum ratings: (1)VDD: 7.0V; (2)All inputs and outputs w.r.t. VSS: -0.6V to VDD +0.6V; (3)Storage temperature: -65℃ to +150℃; (4)Ambient temp. with power applied: -65℃ to +125℃; (5)Soldering temperature of leads (10 seconds): +300℃; (6)ESD protection on all pins: > 4kV.

Features

MCP3004-IP features: (1)10-bit resolution; (2) LSB max DNL; (3) LSB max INL (MCP3201-B); (4) LSB max INL (MCP3201-C); (5)On-chip sample and hold; (6)SPIserial interface (modes 0,0 and 1,1); (7)Single supply operation: 2.7V - 5.5V; (8)100ksps max. sampling rate at VDD = 5V; (9)50ksps max. sampling rate at VDD = 2.7V; (10)Low power CMOS technology; (11)Industrial temp range: -40℃ to +85℃; (12)8-pin PDIP, SOIC and TSSOP packages.
